VORT HRI 350 FLAT IoT

TECHNICAL DATA AND PERFORMANCE DATA

• Filter category in the extract ePM10 50%
• Filter class at flow rate EPM10 50%
• Frequency (Hz)50/60
• Insulation classI°
• IPX2
• Maximum absorbed current (A)1,7
• Maximum absorbed power (W)250
• Nominal diameter (mm)150
• Voltage (V)220-240
• Weight (Kg)35
• Sound breaking power LWA at maximum speed 58,6[dB (A)]
• Sound decay pressure at 3 metres at maximum speed Lp 38,1[dB (A)]
• Heat recovery efficiency in the reference airflow (%)88,4
• Maximum air flow (l/s)100
• Maximum airflow (m³/h)360
• Maximum pressure (mmH2O)53
• Maximum pressure (Pa)520
• Sound power on the exhaust side at maximum speed LWA 59,0[dB (A)]
• Sound power on the power supply side at maximum speed LWA 59,4[dB (A)]
• Sound pressure at 3m at maximum speed on the exhaust side Lp 38,5[dB (A)]
• Sound pressure at 3m at maximum speed on the supply side Lp 38,8[dB (A)]

Technical Data Sheet
