Round duct connection ports, nominal diameter 125 mm.
2 EC (brushless) motors with pivot in bearings, each connected to a forward-curved centrifugal impeller. 3 speeds, independently adjustable during installation.
High performance counter flow heat exchanger in PS resin.
Automatic by-pass for free cooling (manual activation is allowed as an alternative).
1 ePM10 50% (M5) filter in the supply air and 1 ISO Coarse 65% (G4) filter in the exhaust air. The filter clogging status and therefore the need for maintenance is displayed on the control panel.
Control panel, on the front cover, which allows:
• the configuration of the product during installation,
• the manual setting of the operating mode,
• the automatic operation settings and correct operation monitoring,
• the diagnostic system,
• the continuous monitoring of the condition of the filters and the related maintenance/replacement needs,
• firmware updates.
Bracket for wall mounting supplied as standard.
Passivhaus certification.
TECHNICAL DATA AND PERFORMANCE DATA
Filter category in ISOCoarse 65% extract
Filter category at flow rate ePM10 50%
Frequency (Hz) 50/60
Insulation class I° IP X2
Maximum absorbed current (A) 1.35
Maximum absorbed power (W) 190
Nominal diameter (mm) 125
Voltage (V) 220-240
Weight (Kg) 15
Sound breaking power LWA 52,8[dB(A)]
Sound pressure decay at 3 metres at maximum speed Lp 32,3[dB (A)]
Maximum airflow (l/s) 83
Maximum air flow (m³/h) 300
Maximum pressure (mmH2O) 75
Maximum pressure (Pa) 735
Maximum thermal efficiency (%) 92.5
Sound power at the exhaust inlet LWA 46,8[dB(A)]
Sound power at the power outlet LWA 64,9[dB(A)]
Sound pressure at 3m at maximum speed on the exhaust side Lp [dB (A)]
Sound pressure at 3m at maximum speed on the supply side Lp 44,4[dB (A)]
